Good Quality Agricultural Drone - 16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection Spray – Hongfei Detail:

Product Description

Product Description

  T16 T20 T30
Diagonal Wheelbase 1700mm 2000mm
Size (Folded) 870*870*750mm 1000*1000*750mm
Size (Spreaded) 2350*2350*750mm 2000*2000*750mm
Weight 16kg 20kg 30kg
Loading 16kg 20kg 30kg
Spray Width 3-5m 3-6m
Flight Control Systems Microgram V7-AG
Dynamic System Hobbywing X8 Hobbywing X9
Spraying System Pressure Spray
Spraying Flow 1.5-4L/min 1.5-3L/min 1.5-5L/min
Operational 6-12hectares/hour 8-12hectares/hour 12-20hectares/hour
Daily efficiency (6hours) 20-40hectares 20-60hectares 20-60hectares
Power Battery 12S 22000mAh 14S 20000mAh 14S 28000mAh
Recharge Cycles 300-500times

The HGS series agricultural drone, which integrates intelligent sowing and precise spraying, can flexibly carry different capacity operation boxes and easily and efficiently carry out sowing, spreading fertilizer, application and feeding in all terrain conditions through cell phone or intelligent remote control, providing every user with intelligent, precise, efficient and flexible production solutions.The new HGS series agricultural drone allows every user, through low production costs, to create high efficiency.16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection SprayFeatures

1. Android cell phone ground station, using simple/PC ground station, the whole voice broadcast.

2. Support one key take-off and landing, no manual intervention, improve safety.

3. Breakpoint spraying, no medicine, low power return.

4. Dosage detection, can be set without drugs automatically record break point return.

5. Power detection, can be set to low power automatically record the break point return.

6. Microwave altitude radar, stable altitude, support ground-like flight.

7. Fence function, log storage function, landing lock function, no-fly zone function.

8. Vibration protection, star loss protection, drug break protection.

9. Motor sequence detection function, direction detection function.

10. Double pump mode.





Whole Machine Design

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection SprayThe modular waterproof body folding design, large-diameter 16-liter rotomolding process anti-vibration water tank, the main body of the body using aluminum alloy integrated plastic into.Shell using ABS injection molding, the surface using piano baking paint process, wear-resistant and easy to clean.





Protection Grade

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection SprayProtection class IP67, waterproof and dustproof, support full body wash.





Accurate Obstacle Avoidance

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection SprayFront and rear dual FPV cameras, spherical omnidirectional obstacle avoidance radar to provide security escort, real-time perception of three-dimensional environment, omnidirectional obstacle avoidance.





Product Detail

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection Spray·8 groups of solenoid valves with full frequency control, providing a strong flow rate of 1L/min.

·4 nozzles full-coverage spraying (can be customized), spraying width up to 4-6 meters.

·New intelligent liquid level meter, accurate prediction of the change of drug point, significantly improve the efficiency of the battery change.





Fast Charging

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection SprayInverter charging station, generator and charger in one, 30 minutes fast charging.

Battery weight 6.3KG
Battery specification 12S 22000mah
Charging Time 0.5-1 hour
Recharge Cycles 300-500 times





Standard Configuration

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection Spray16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection Spray





Optional Configuration

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection Spray

Company Profile

16L 20L 30L Agricultural Spray Motor Brushless Drone for Agricultural Plant Protection Spray

FAQ

1.What is the best price for your product?

We will quote based on the quantity of your order, the higher the quantity the higher the discount.



2.What is the minimum order quantity?

Our minimum order quantity is 1 unit, but of course there is no limit to the number of units we can purchase.



3.How long is the delivery time of the products?

According to the production order dispatch situation, generally 7-20 days.



4.What is your payment method?

Wire transfer, 50% deposit before production, 50% balance before delivery.



5.What is your warranty time? What is the warranty?

General UAV frame and software warranty of 1 year, the warranty of wearing parts for 3 months.
