HE-280B2 Two Stroke Piston Engine for Drones
Insufficient engine power, uncontrolled fuel consumption, and poor adaptability to working conditions are often key bottlenecks. Traditional carburetor engines have cumbersome start-ups, inaccurate fuel mixing, are prone to flameouts in high-altitude or low-temperature environments, and incur high maintenance costs. The HE-280B2 EFI aviation engine addresses these issues with precise electronic control technology, balancing high power output with a lightweight design, and providing stable and reliable power cores.
Product Parameters
| Parameter Category | Specific Specification |
| Displacement | 280cc |
| Weight | 7.5kg |
| Bore | 66mm |
| Stroke | 41mm |
| Max. Continuous Speed | 7000RPM |
| Rated Maximum Power | 17KW@6500RPM |
| BSFC at Cruise | 400-480g/kwh |
| TBO | 100 Hours |
| Fuel to Oil Mixture Ratio | 40:1 |
Product Details
· 280cc Displacement, 17KW Rated Power: 280cc displacement, the maximum rated power reaches 17KW@6500RPM. Abundant power easily adapts to the high-intensity operation needs.
· 7.5kg Lightweight Design: Only 7.5kg including the electronic fuel injection system. Ultimate weight reduction effectively improves the endurance and flight maneuverability of UAVs.
· Precise Proportioning of Electronic Fuel Injection: Equipped with a professional EFI system, abandoning the manual proportioning of traditional carburetors, realizing precise fuel control under all working conditions, lower fuel consumption, and 15% higher combustion efficiency.
· 28V/18A Power Generation System Output: Built-in 28V/18A power generation system, continuously supplies power for equipment, no need to carry additional power supply modules, saving the whole machine space.
